MOV-S Series MONO Flange Valve – Single Block

SKU: MOV-S

Single-block mono flange valve with ASME B16.5 flange inlet connection shown.

Features

  • Standard 1/ 2″ NPT female out let.
  • ASME B16.5 flanged inlet connect ions 1/ 2″ to 2″sizes.
  • Needle valve with PTFE packing is standard, optional Graphite.
  • Bleed port 1/2′ NPT female with hex plug is standard.
  • Optional fire safe design to BS6755 Part 2.
  • Ratings: Classl 500 to 2500
  • 100% Gas tested
