BH / BH3 Series Ball Valves

Features

• High pressure up to 10,000 psi (689 bar).
• Blowout proof design with internally loaded stem.
• Handle indicates the flow direction.
• Positive stop with a robust stop pin.
• Available in pneumatic.

Specifications

• Pressure rating: up to 10000 psig (690 bar)
• Temperature rating: -40 °F to 450 °F (-40°( to 232°C )
• Optional pneumatic and electric actuator

Pneumatic Actuator Ball Valve

Technical Information

• Standard : NBR 0 -Ring – 20 to 80.
• Low Temperature : Silicon 0 -Ring -40 to 80
• High Temperature : FKM 0 -Ring -15 to 150
• Ai r-pressure: Min. 2.5 bar, Max. 8 bar.
• Air supply end connection : Female G 1/8 inch (ISO 228-1).
• Position indicator is standard.
